PVC-laminated steel, also known asPVC-laminated steel, VCM sheet(Vinyl-coated metal sheet), orPVC-coated steelis a high-performance composite material that combines the benefits of metal and polymer. It is manufactured by bonding a premium PVC (polyvinyl chloride) film to a metal substrate—typically cold-rolled steel, galvanized steel, aluminum alloy, or stainless steel—using a professional high-temperature, high-pressure lamination process.
PVC Laminated Steel Sheet(also known as PVC film-coated steel, VCM sheet, or PVC-coated steel) is a high-performance composite material. It is produced by bonding premium-quality PVC (polyvinyl chloride) film to a metal substrate—typically cold-rolled steel, galvanized steel, aluminum alloy, or stainless steel—using a specialized high-temperature and high-pressure lamination process. This integrates the advantages of both metal and polymer materials.
PVC Clad Steel Sheet Product Structure Diagram - Combining the Strength of Steel with the Aesthetics and Durability of PVC
Core Advantages
Excellent Decorative Performance
PVC film comes in a wide range of colors, patterns, and textures—including wood grain, marble, metallic finishes, and solid colors—to meet diverse aesthetic needs for architectural decoration, furniture, and home appliances.
PVC films offer a wide range of colors, patterns, and textures—including wood grain, marble, metal, and solid hues—to meet diverse aesthetic needs in architectural decoration, furniture, and home appliances.
Superior Corrosion and Weather Resistance
The PVC film effectively blocks moisture, chemicals, and UV radiation to significantly extend product lifespan. Includes UV protection for 5–10 years of fade-resistant outdoor performance.
PVC film effectively isolates moisture, chemicals, and UV radiation, significantly extending product lifespan. With UV protection factors, it remains fade-resistant for 5-10 years outdoors.
High Mechanical Strength
Retains the metal substrate's superior mechanical strength, rigidity, and load-bearing capacity, making it ideal for high-strength structural applications.
Inherits the excellent mechanical strength, rigidity, and load-bearing capacity of metal substrates; ideal for high-strength structural applications.
Easy to Install and Use
Supports cutting, bending, punching, and other processing methods. Can be laminated first, then embossed, seamlessly integrating with embossed door panel processes.
Supports cutting, bending, stamping, and other processing methods. Can be laminated before embossing for seamless integration with embossed door panel craftsmanship.
Production Process
- 1
Steel Coil Uncoiling
High-quality cold-rolled steel, galvanized steel, or aluminum alloy coils are loaded onto the uncoiler for precise feeding.
Load premium cold-rolled steel, galvanized steel, or aluminum alloy coils onto the uncoiler for precise feeding.
- 2
Surface Treatment
Chemical cleaning and degreasing to remove oil, rust, and impurities from the metal surface, ensuring strong PVC film adhesion.
Chemical cleaning and degreasing to remove oil, rust, and impurities from metal surfaces, ensuring strong adhesion of the PVC film.
- 3
Roll Coating (Adhesive)
Apply special adhesive uniformly to the metal surface using precision roller coating equipment.
Apply a specialized adhesive uniformly onto the metal surface using precision roller coating equipment.
- 4
Heat Laminating & Pressing
Under high-temperature and high-pressure conditions, the PVC film is firmly bonded to the metal substrate via roller pressing.
Bond PVC film to metal substrate securely via calendering under high temperature and pressure.
- 5
Cooling & Shaping
Rapidly cool through cooling rollers to solidify the adhesive and maintain the composite material's dimensional stability.
Rapidly cool via a cooling roll to cure the adhesive and ensure dimensional stability of the composite.
- 6
Rewinding & Inspection
Automatic rewinding followed by strict quality inspection, including adhesion testing, surface quality checks, and dimensional verification.
Automatically rewind and perform rigorous quality inspection, including adhesion testing, surface quality checks, and dimensional verification.
PVC Laminated Steel Sheet: Production Process Flowchart and Product Specifications
Application Fields
Home Appliance Manufacturing
Refrigerator door panels, washing machine casings, water heater outer cylinders, microwave oven panels, and air conditioner housings.
Home Appliance Manufacturing
Refrigerator door panels, washing machine casings, water heater outer drums, microwave control panels, and air conditioner housings.
Architectural Finishes
Interior wall panels, cabinet doors, ceiling materials, elevator finishes, outdoor signage, and curtain wall panels.
Building Decoration
Indoor wall panels, cabinet doors, ceiling materials, elevator finishes, outdoor signage, and curtain walls.
Furniture Manufacturing
Wardrobe doors, office desks, kitchen cabinets, bookcases, TV stands, and commercial display cases.
Furniture Manufacturing
Wardrobe doors, office desks, kitchen cabinets, bookcases, TV stands, and commercial display cases.
Door & Panel Manufacturing
Embossed door panels, medical-grade door panels, fire-rated doors, wall panels, cleanroom doors.
Door Panel Manufacturing
Embossed door panels, medical door panels, fire-rated door panels, wall panels, and cleanroom door panels.
Industrial Equipment
Protective casings, equipment panels, control box enclosures, and machine housings.
Industrial Equipment
Protective housing, equipment panel, control box enclosure, machine casing.
Commercial Display
Shopping mall displays, exhibition booths, retail store fixtures, and hotel decor.
Commercial Showcase
Mall display cases, exhibition booths, retail store fixtures, and hotel decor.
Technical Specifications
| Item | Item | Specification |
|---|---|
| Base Material | Cold-Rolled Steel (CR), Galvanized Steel (GI), Aluminum Alloy, Stainless Steel |
| Thickness | 0.18mm - 1.2mm (Customizable) |
| Width | 600mm - 1250mm (Customizable) |
| Length | Coil / Sheet (Customizable) |
| PVC Film Thickness | 0.08mm - 0.25mm |
| Surface Finish | Glossy, Matte, Embossed, Wood Grain, Marble, Metallic, Solid Color |
| Protective Film | PE Protective Film (Optional) |
| Color | RAL Color / Custom Color |
| Fire Rating | B1 (Fire-Retardant Grade Available) |
| Weather Resistance | 5-10 Years of Outdoor Use (with UV Protection) |
Why Choose Wuyi Qifan Metal?
Professional Manufacturer
15+ years of industry experience, ISO9001 certified, serving 100+ enterprise clients worldwide.
15+ years of industry experience, ISO9001 certified, serving 2+ global enterprise customers.
Advanced Production Line
Modern PVC-laminated steel production line with a daily capacity of 50–80 tons, featuring precision coating technology.
Modern PVC film-coated steel production line with a daily capacity of 50-80 tons, featuring precision coating technology.
Quality Assurance
Rigorous quality control meeting export standards. Products shipped to Europe, Southeast Asia, the Middle East, and Africa.
Rigorous quality control system meeting export standards. Products exported to Europe, Southeast Asia, the Middle East, and Africa.
Customization Service
Supports custom substrate materials, PVC film thickness, color, pattern, and size. Flexible MOQ for small-batch orders.
Customizable base material, PVC film thickness, color, pattern, and size. Flexible MOQ with small-batch orders supported.
